  2. Two steps to enable ZTE MC315 CDMA 1X Reliance. Step 1. Insert the card and do dmesg as root output : 0.0: ttyS0 at I/O 0x2e8 (irq = 3) is a 16C950/954 Step 2. edit /etc/wvdial.conf [Dialer Reliance] Modem = /dev/ttyS0 Baud = 57600 SetVolume = 0 Dial-AT-OK ATDT Command = Init1 = ATZ FlowControl = Hardware (CRTSCTS) Phone = #777 Username = Password = New PPPD = yes Carrier Check = no Stupid Mode = 1 Before running wvdial Reliance do following The trick is simple - you have to play with the UART and the baud_base. Just run setserial on your machine and it will give the following output for UART and baud_base * uart set UART type (none, 8250, 16450, 16550, 16550A, 16650, 16650V2, 16750, 16850, 16950, 16954) * baud_base set base baud rate (CLOCK_FREQ / 16) What i did was that i kept on changing my UART and kept the baud_base as 230400. When I changed my UART to 16550A. And i got connected to the internet running wvdial Reliance [Fyi: I am sending this information using ZTE MC315 CDMA 1X Reliance connected on OS FC5.]
  3. By Ram Bhupal Reddy IIIT, Hyderabad. Two steps to enable ZTE MC315 CDMA 1X Reliance. Step 1. Insert the card and do dmesg as root output : 0.0: ttyS0 at I/O 0x2e8 (irq = 3) is a 16C950/954 Step 2. edit /etc/wvdial.conf [Dialer Reliance] Modem = /dev/ttyS0 Baud = 57600 SetVolume = 0 Dial-AT-OK ATDT Command = Init1 = ATZ FlowControl = Hardware (CRTSCTS) Phone = #777 Username = Password = New PPPD = yes Carrier Check = no Stupid Mode = 1 Before running wvdial Reliance do following The trick is simple - you have to play with the UART and the baud_base. Just run setserial on your machine and it will give the following output for UART and baud_base * uart set UART type (none, 8250, 16450, 16550, 16550A, 16650, 16650V2, 16750, 16850, 16950, 16954) * baud_base set base baud rate (CLOCK_FREQ / 16) What i did was that i kept on changing my UART and kept the baud_base as 230400. When I changed my UART to 16550A. And i got connected to the internet running wvdial Reliance [Fyi: I am sending this information using ZTE MC315 CDMA 1X Reliance connected on OS FC5.]
×
